Immense

ALKALINE
BATTERIES

TYPE DIAMETER HEIGHT WEIGHT CAPACITY TESTING CONDITION
LR20 32.3~34.2mm59.5~61.5mm0.1406kg18000mAh25mA,24h/d,20oC,e.v.=0.8V
LR1424.9~26.2mm48.6~50.0mm0.0681kg7500mAh25mA,24h/d,20oC,e.v.=0.8V
6LR61L(26.3~26.5)mm
W(17.3~17.5)mm		48.3~48.5mm0.045kg500mAh35mA,24h/d,20oC,e.v.=5.4V
LR613.5~14.5mm49.2~50.5mm0.023kg2650mAh10mA,24h/d,20oC,e.v.=0.8V
LR039.5~10.5mm43.3~44.5mm0.0114kg1300mAh10mA,24h/d,20oC,e.v.=0.8V
LR8D4257.7~8.3mm41.5~42.5mm0.0068kg500mAh35mA, 24h/d, 20oC, e.v.=0.9V
TEST MODECUT-OFFDURATIONAPPLICATIONS
LR20 / AM1 / SIZE D / 1.5V
10Ω4h/d0.9V125hRadio
2.2Ω1h/d0.8V23.5hToy
2.2Ω4min/h, 8h/d0.9V22hPortable lighting(1)
600mA2h/d0.9V15.5hPortable Stereo
1.5Ω4min/15h, 8h/d0.9V14hPortable lighting(2)
2.2Ω24h/d0.9V19hFasttest
LR14 / AM2 / SIZE C / 1.5V
3.9Ω4min/h, 8h/d0.9V20hPortable lighting
20Ω4h/d0.9V120hRadio
400mA2h/d0.9V11.5hPortable Stereo
3.9Ω1h/d0.8V21hToy
3.9Ω24h/d0.9V18hFast test
6LR61 / 9V
620Ω2h/d5.4V46hRadio
270Ω1h/d5.4V19hToy
35mA24h/d5.4V15hFasttest
LR6 / AM3 / SIZE AA / 1.5V
10Ω24h/d0.9V19.5hFasttest
1000mA24h/d0.9V50 minFasttest
1.5W/0.65W2s/28s,5min/h1.05V65 pulsesDigital camera
1000mA10s/min,1h/d0.9V450 pulsesPhoto flash
43Ω4h/d0.9V90hRadio
3.9Ω1h/d0.8V7.5hToy
10Ω1h/d0.9V19.5hTape recorder
250mA1h/d0.9V7.5hElectronic games
24Ω15s/min, 8h/d1.0V44hRemote control
LR03 / AM4 / SIZE AAA / 1.5V
20Ω24h/d0.9V18.5hFast test
600mA24h/d0.9V37minFast test
600mA10s/min,1h/d0.9V350pulsePhoto flash
5.1Ω4min/h,8h/d0.9V240mPortable lighting
10Ω1h/d0.9V8.5hTape recorder
24Ω15s/min, 8h/d1.0V20.5hRemote control
75Ω4h/d0.9V73hRadio
LR8D425 / SIZE AAAA /1.5V
5.1Ω5min/h0.9V110mLighting
35mA24h/d0.9V15hFast test
75Ω1h/d0.9V33hLaser pointer

IMMENSE Alkaline Batteries

"CHOOSE US FOR LONG LASTING POWER"
